Woodpecker LX16 Plus Dental Diode Laser – main unit
  • Woodpecker LX16 Plus Dental Diode Laser – main unit
  • Woodpecker LX16 Plus Dental Diode Laser – handpiece and fiber tip
  • Woodpecker LX16 Plus Dental Diode Laser – foot pedal
  • Woodpecker LX16 Plus Dental Diode Laser – safety goggles
  • Woodpecker LX16 Plus Dental Diode Laser – power adapter
  • Woodpecker LX16 Plus Dental Diode Laser – in clinical use
  • Woodpecker LX16 Plus Dental Diode Laser – packaging box
Woodpecker LX16 Plus Dental Diode Laser

Versatile laser for soft tissue treatments.

4.1
(63)
Rs. 199,000.00
Taxes included. Shipping calculated at checkout.

What's Inside

1 items
FREE Delivery
Jun 29 - Jul 04
Order within
-- h : -- m

HUMAN SKIN LIKE

Same day Shipping

READY TO USE

Beginer Friendly
Key Specifications

Power adapter input：100-240Vac，50/60Hz，2.5A
Main unit input：15V 6.0A
Wavelength and power:

976± 20nm ： 0.2W-4W(CW), Peak Power 5W chopped 1Hz to 20KHz
chopped mode :5us – 0.9S
650± 20nm ： 25mW-200mW(CW)
450± 20nm ： 0.2W-3W(CW) chopped 1Hz to 20KHz
chopped mode : 5us – 0.9S
Laser classification:

976 nm: Class 4
650 nm: Class 2
450 nm: Class 4
Aiming beam: 650 ± 20 nm / Pmax<5mW (class 1 )
Aiming beam: 650 ± 20 nm /Pmax<5mW
Divergence:12.7°(According to IEC 60825-1: 2014)
Rechargeable battery: 11.1V/2600mAh x2 (57.7Wh)
Time consumption for charging: about 4h (5 hours for first charging)
Diverging half angle: 0.22 mad/ 12.6 °
size: 22 cm x 20cm x 23cm
Weight: 1.5kg
Direction To Use

Here are the directions for using the Woodpecker LX16 Plus Dental Diode Laser:

Unboxing and Setup:

  • Carefully remove all parts from the packaging, ensuring no damage occurs.
  • Install the device in the designated area with ample space around it to prevent damage to the fiber handpiece wire.
  • Ensure there are no obstructions blocking the device's air outlet.

Installation of Power Adapter:

  • Connect the provided power adapter and power supply cable as indicated in the instructions.

Installation and Removal of Dustproof Plug:

  • Remove the dustproof plug on the handpiece counterclockwise when ready to use.
  • Tighten the dustproof plug clockwise when the device is not in use to prevent dust from entering the handpiece tip.

Installation and Removal of Handpiece Sleeve:

  • Carefully insert the handpiece sleeve into the handpiece, ensuring it is securely in place.
  • Press the handpiece switch to remove the sleeve when disassembling.

Storage of Handpiece Tail Cord:

  • Handle the handpiece tail cord delicately to avoid damage.
  • Store the cord as shown in the instructions to prevent bending or squeezing.

Operation:

  • Turn on the device by pressing the "ON/OFF" button at the back.
  • Enter the user password (initial password: "8888") on the display screen and press OK.
  • Select a preset program or customize treatment parameters as needed.

Laser Emission:

  • Ensure the aiming beam is working properly before each treatment.
  • Press the pedal to observe the indicator light and initiate laser emission.
  • Monitor the device during laser emission and observe safety protocols.

Charging and Control Modes:

  • Charge the device using the provided power adapter.
  • Switch between footswitch control mode and handpiece control mode as needed.
  • Pair the footswitch with the main unit if necessary.

Troubleshooting:

  • Refer to the troubleshooting guide provided if encountering operational issues.
  • Contact the dealer or manufacturer for assistance if problems persist.
Packaging
{"type":"root","children":[{"type":"list","listType":"unordered","children":[{"type":"list-item","children":[{"type":"text","value":"1 x Laser"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Handleshell"}]},{"type":"list-item","children":[{"type":"text","value":"2 x MF2-14"}]},{"type":"list-item","children":[{"type":"text","value":"1 x MF2-20"}]},{"type":"list-item","children":[{"type":"text","value":"3 x MF3-4\n"}]},{"type":"list-item","children":[{"type":"text","value":"3 x MF3-9"}]},{"type":"list-item","children":[{"type":"text","value":"3 x MF4-4"}]},{"type":"list-item","children":[{"type":"text","value":"3 x MF4-9"}]},{"type":"list-item","children":[{"type":"text","value":"3 x Goggles"}]},{"type":"list-item","children":[{"type":"text","value":"1 x DT15-Tip"}]},{"type":"list-item","children":[{"type":"text","value":"1 x DT20-Tip"}]},{"type":"list-item","children":[{"type":"text","value":"1 x DT30-Tip"}]},{"type":"list-item","children":[{"type":"text","value":"1 x BT8-Tip"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Whitening-Tip"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Bending tool"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Articulating paper"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Cutting Pen"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Remote con trol interlock"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Adapter"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Foot Switch"}]},{"type":"list-item","children":[{"type":"text","value":"1 x Instruction manual"}]}]}]}
Additional Info

Country of Origin: PRC
Manufacturer: Woodpecker

Payment Options

COD
Net Banking
UPI
Wallet
Cards
EMI

AeDental Benefits

Free
Shipping
Hassle Free
Cancellation
10 Days
Replacement
100%
Genuine

Detail Title

Detail description goes here

Got Any Doubts?
What are the main clinical applications for this diode laser?

This laser is indicated for various dental applications, including soft tissue surgeries and pain management. Its 976nm wavelength is ideal for soft tissue procedures due to its high absorption by water and hemoglobin.
What are the device's main wavelengths and power ranges?

The laser operates at three primary wavelengths: 976nm with a power range of 0.2W-4W, 450nm with a range of 0.2W-3W, and 650nm with a range of 25mW-200mW. It has a total power output of up to 16 watts.
How is the laser operated during a procedure?

The device is operated via an intuitive touch screen interface that allows for precise parameter adjustments. It also includes a wireless foot pedal for convenient, hands-free control during procedures.
Does this laser come with pre-set settings?

Yes, the laser comes with a range of pre-set programs for common procedures. It also offers the flexibility to customize and save settings according to specific treatment requirements.
Is this laser portable and how is it powered?

Yes, the device has a compact design and weighs 1.5kg, making it portable for use in different treatment rooms. It is powered by a rechargeable battery that requires approximately 4 hours to charge.
